Stallion 4×4 MK IV
Ashok Leyland Stallion 4x4 MK IV Overview
- Engine: The vehicle is powered by a 180 hp diesel engine, featuring a 6-cylinder configuration. The engine is water-cooled and turbocharged, with an inline fuel pump. It delivers a maximum torque of 670 Nm.
- Transmission: The Stallion 4x4 MK IV comes with a manual transmission system that includes 6 speeds.
- Steering: It features integral power steering and supports both left-hand (LH) and right-hand (RH) drive configurations.
- Dimensions:
- Wheelbase: 3607 mm
- Overall length: 8000 mm
- Overall width: 2500 mm
- Overall height: 3000 mm
- Angle of Approach: 25°
- Angle of Departure: 30°
- Ground Clearance: 305 mm
- Weight and Capacity:
- Gross Vehicle Weight (GVW): 14,750 kg
- Payload capacity: 5000 kg
- Fuel tank options: 160, 250, 320 liters
- Suspension: The vehicle is equipped with semi-elliptic multi-leaf spring suspension, along with double-acting telescopic shock absorbers at both the front and rear.
- 4x4 capability, ensuring excellent off-road maneuverability
- Capable of navigating diverse terrains, including mud, sand, and rough landscapes
- Configurable for different military applications and equipment mounting
- Designed to carry heavy loads, crucial for military logistics
- Diesel-powered engine for reliable performance
- Ergonomic design for prolonged use and operational comfort
- Robust chassis construction for resilience in tough environments
ENGINE | TRANSMISSION | ||
Max Power | 180 hp | Type | Manual |
Max Torque | 670 Nm | Number of Speeds | 6S |
Type | Diesel, 6 Cylinder, water-cooled, turbocharged & Inline fuel pump | WEIGHT | |
DIMENSION | GVW | 14750 kg | |
Wheelbase | 3607 mm | Fuel Tank | 160, 250, 320 Litres |
Overall Max Length | 8000 mm | Payload | 5000 kg |
Overall Width | 2500 mm | SUSPENSION | |
Overall Height | 3000 mm | Type | Semi-elliptic multi-leaf spring with Double acting telescopic shock absorber at Front & rear |
Angle of Approach | 25° | STEERING | |
Angle of Departure | 30° | Steering Type | Integral Power Steering |
Ground Clearance | 305 mm | Configuration | LH & RH Drive Configuration |
The Ashok Leyland Stallion 4x4 MK IV is a robust military truck designed and manufactured by Ashok Leyland, India's leading commercial vehicle manufacturer. It is engineered to meet the stringent requirements of military operations, offering exceptional performance and reliability in diverse terrains and adverse conditions. Powered by a diesel engine, the Stallion 4x4 MK IV provides ample torque and power for both on-road and off-road missions, ensuring superior mobility and operational flexibility.
Built on a sturdy chassis, the Stallion 4x4 MK IV boasts a high payload capacity, making it suitable for transporting troops, equipment, and supplies across challenging landscapes. Its 4x4 drivetrain enables it to navigate through rough terrain, including mud, sand, and rocky surfaces, essential for military operations in varied environments. The vehicle's design emphasizes durability, ease of maintenance, and operator comfort, featuring ergonomic seating and modern instrumentation.
Adaptable to various military configurations, the Stallion 4x4 MK IV can accommodate specialized equipment and weapons systems, enhancing its versatility and utility in combat and logistical roles. It exemplifies Ashok Leyland's commitment to delivering robust defense solutions tailored to meet the demanding needs of armed forces worldwide.
