SCHOOL BUS 4020
Description
  • Make Force Motor
  • Model SCHOOL BUS 4020
  • Engine Type FM 2.6 CR ED
  • Maximum Power 85kW (114hp) @ 2950 rpm
  • Transmission Type Manual, Synchromesh
  • Ground Clearance 180mm
  • Bore x Stroke 90.9 x 100
  • Displacement 2596 cc
  • Fuel Tank Capacity 70 Litres / 23.5 Litres
  • Width/Length/Height (mm) 2385/6970/2670
  • Suspension Spring Semi Elliptical
  • Torque 350Nm @ 1400-2200 rpm
  • Emission BS-VI Stage 2

An overview of the Force Motors School Bus 4020 in bullet points:

  • Engine: Powered by a FM2.6 CR ED engine delivering 114hp and 350Nm of torque, ensuring efficient performance.
  • Emission: Compliant with BS-VI Stage 2 emission norms, promoting eco-friendly operation.
  • Transmission: Equipped with a manual 5-speed gearbox (G32-5), offering smooth gear transitions for easy handling.
  • Construction: Built with a monocoque body, enhancing safety and structural integrity.
  • Suspension: Features spring semi-elliptical suspension with hydraulic telescopic shock absorbers for a smoother ride.
  • Braking System: Comes with dual-circuit hydraulic brakes, ABS, EBD, and ESP (for T2 models) for superior control and safety.
  • Capacity: Available in two seating configurations – 24+A+D (2x2) and 30+A+D (3x2), designed for efficient student transport.
  • Dimensions: Spacious design with a wheelbase of 4020mm, overall length of 6970mm, and height options of 2670mm or 2870mm.
  • Fuel Tank: Equipped with a 70-litre fuel tank and 23.5-litre AdBlue capacity for long-distance travel.
  • Ground Clearance: 180mm ground clearance, ideal for varied road conditions.
  • 30+A+D
  • ABS and EBD
  • Emergency Exit Door for Easy Exit
  • First Aid Kit & Fire Extinguishers in case of an emergency
  • Large Internal Rear View Mirror and Driver partition
  • Mercedes derived, Highly Powerful and fuel efficient FM 2.6 SNG Power train
  • Now, with Best-in-Class FIRE ALARM PROTECTION SYSTEM for more safety in case of fire
ENGINE BRAKES
Engine FM2.6CR ED Service Brakes Dual circuit, hydraulic, vacuum assisted ABS with EBD and ESP (for T2)
Bore x Stroke (mm) 90.9 x 100 Auto Slack Adjuster Yes
Emission BS-VI Stage 2 Front Brakes Disc
Type 4 Cyl. Common Rail, DI TCIC Rear Brakes Drum
Displacement (cc) 2596 cc Parking Brake Mechanical acting on Propeller shaft
Max Output 85kW (114 hp) @ 2950 rpm CAPACITY
Max Torque 350 Nm @ 1400 - 2200 rpm Fuel & AdBlue Capacity 70 Litres / 23.5 Litres
TRANSMISSION DIMENSIONS (mm)
Type Manual, Synchromesh Wheel Base 4020
Make & Model G32-5 Overall Length 6970
No. of Gears 5 Forward + 1 Reverse Overall Width 2385
BODY Overall Height 2670 / 2870
Type Monocoque Construction Ground Clearance 180
SUSPENSION WEIGHT (kg)
Front and Rear Spring Semi Elliptical Maximum GVW 6000
Anti Roll Bar Front - Yes; Rear - Optional SEATING CAPACITY
Shock Absorbers Hydraulic telescopic double acting at front and rear Seating Capacity 24 + A + D (2X2) / 30 + A + D (3X2)



The Force Motors School Bus 4020 is a well-engineered vehicle specifically designed to ensure the safety, comfort, and convenience of school transportation. Built with a robust monocoque construction, the bus offers enhanced durability and safety, ensuring a solid and protective frame for students during transit. The bus is powered by the FM2.6 CR ED engine, a reliable and efficient 4-cylinder unit with a displacement of 2596cc. This engine delivers a power output of 114hp at 2950 rpm and a peak torque of 350Nm between 1400-2200 rpm, ensuring the bus has enough power to handle various terrains and loads while maintaining fuel efficiency.

Complying with BS-VI Stage 2 emission standards, the Force Motors School Bus 4020 adheres to modern environmental norms, reducing harmful emissions and contributing to a cleaner environment. The manual transmission with a G32-5 gearbox provides smooth gear transitions, making the vehicle easy to handle for drivers, even in urban traffic conditions.

The school bus features spring semi-elliptical suspension at both the front and rear, combined with hydraulic telescopic double-acting shock absorbers, ensuring a smooth ride for students, even on uneven roads. The anti-roll bar at the front, and optionally at the rear, adds stability to the vehicle, further enhancing safety. Equipped with ABS, EBD, and ESP (Electronic Stability Program for T2 models), the bus delivers advanced braking capabilities, ensuring precise control and reducing the risk of accidents.

In terms of dimensions, the School Bus 4020 offers ample space with an overall length of 6970mm, a width of 2385mm, and height options of 2670mm or 2870mm, depending on the model variant. The 4020mm wheelbase allows for better weight distribution and stability, while the ground clearance of 180mm helps the bus navigate various road conditions with ease.

This bus is available in two seating configurations: 24+A+D (2x2) and 30+A+D (3x2), accommodating students comfortably and efficiently. Additionally, with a 70-litre fuel tank and 23.5-litre AdBlue capacity, the Force Motors School Bus 4020 is designed for long trips, minimizing the need for frequent refueling stops.

The Force Motors School Bus 4020 is a reliable, safe, and economical choice for school transportation, offering a balance between power, safety features, and passenger comfort, making it an ideal solution for schools seeking dependable transit options for their students.
